3KW Powerwall Lithium Battery MPPT Off Grid Solar Inverters With 60A Solar Charge Controller

Product Categories

Shenzhen SunFiD New Energy Co.,Ltd

Contact Now

Name: 3KW Powerwall Lithium Battery MPPT Off Grid Solar Inverters With 60A Solar Charge Controller
Brand: SUNFiD
Price: 1 USD

Brand Name : SUNFiD

Model Number : HF2430S60-100

Certification : CE,FCC,MSDS,ROHS,UN38.3

Place of Origin : CHINA

MOQ : 50pcs

Price : Negotiable Price

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1000 pcs per month

Delivery Time : 10-30 days

Packaging Details : Hard Paper Carton with Foam From Top and Button

Input Voltage : 220/230Vac

Output Voltage : 230Vac

Output Current : 60A

Product name : 3KW MPPT Off grid Solar Inverters With 60A Solar Charge Contr

Rated Power : 3000W

Contact Now

Powerwall Lithium Battery 3KW MPPT Off grid Solar Inverters With 60A Solar Charge Controller

Specifications:

Models	HF2420S60-100	HF2430S60-100
AC mode
Rated input voltage	220/230Vac
Frequency	50Hz/ 60Hz (Auto detection)
Maximum bypass overload current	30A
Inverter mode
Output voltage waveform	Pure sine wave
Rated output power (VA)	2000	3000
Rated output power (W)	2000	3000
Power factor	1
Rated output voltage (Vac)	230Vac
Loaded motor capability	1HP	2HP
Bypass breaker specifications	30A
Rated battery input voltage	24V (Minimum starting voltage 22V)
AC charging
Battery type	Lead acid or lithium battery
Maximum charge current	60A	80A
Circuit breaker specifications	30A
PV charging
Maximum PV open circuit voltage	100Vdc
PV operating voltage range	30-100Vdc
Maximum output power	1400W
PV charging current range (can be set)	0-60A
Communication interface
Communication interface	USB/RS485(WiFi/GPRS)/Dry node control

3KW Powerwall Lithium Battery MPPT Off Grid Solar Inverters With 60A Solar Charge Controller
